C to C charger

! Rushabh | Linux ShillAug 20, 2026, 4:06 PM

J1 is rotated 180 igg

! Rushabh | Linux ShillAug 20, 2026, 4:07 PM

also its silkscreen is rotated 90

techmannihAug 20, 2026, 4:10 PM

exactly. The plug should be inside J1.

! Rushabh | Linux ShillAug 20, 2026, 4:11 PM

but the silkscreen

techmannihAug 20, 2026, 4:11 PM

silkscreen for what?

! Rushabh | Linux ShillAug 20, 2026, 4:12 PM

techmannihAug 20, 2026, 4:12 PM

ooh noticed

! Rushabh | Linux ShillAug 20, 2026, 4:14 PM

is it a easyeda issue

techmannihAug 20, 2026, 4:14 PM

But it’s imported the same way. I’m not sure why.

techmannihAug 20, 2026, 4:15 PM

yea

! Rushabh | Linux ShillAug 20, 2026, 4:15 PM

will take a look soon

techmannihAug 20, 2026, 4:16 PM

No, I don't think it's an EasyEDA issue. They provided it in that way.

! Rushabh | Linux ShillAug 20, 2026, 4:18 PM

ooh
